- Human Presence Sensor support Motion, stillness, and micro motion detetion, supports infrared PIR and 24G radar dual detection algorithms which can effectively filter out interference from non-human moving targets such as curtains and green plants
- When someone is detected indoors, the lights automatically turn on and remain on, and when a person leaves the room
- Built-in WiFi chip ,can be easily connected for Tuya globalization intelligent platform, and through Smart Life App, it can achieve intelligent linkage with other devices, such as curtains，lights, fans, air conditioners, purifiers, etc.
- Up to 6M sensing distance, adjustable in 8 gear sensing distances, with a maximum sensing angle of 120 ° (± 60 °), enabling precise indoor detection over long distances and angles
- The product size is 52 * 19mm, lightweight and compact. Supports wall and top mounted installation methods, making installation easy, convenient, and fast, Easy to match with various indoor styles
Executive standard: GB 4943.1-2022
Model: XM-HE201
Product size: 52 * 19mm
Power supply input: DC5V 1A
WiFi frequency band: 2.4GHz
Radar frequency: 24GHz
Light sensing range: 0~16000lux
Working temperature: -10°C~40°C
Working humidity: 0-95% RH, non condensing
24G radar infrared detection
Accurate detection of motion/static human body
Long sensing distance and large angle
Maximum 6M sensing distance, 8 gear adjustable
Maximum 120 ° (± 60 °) sensing angle
Connected for tuya intelligent
When the light is on, when the light is off
People in the air conditioning on, people in the air conditioning off
No human exists detection
1-999S range, adjustable in seconds
Proximity and distance detection
3-speed sensitivity setting for more accurate sensing
8 gear space
8 gear sensing distance setting
Professional illumination chip
Illumination recognition range can reach 0~10000lux
Installation method
Side/ceiling design with various home styles
